Convert a set of ggplot2 maps to an atlas — make

make_atlas() is a wrapper for papersize::page_layout() and papersize::map_ggsave_ext() with the intent for taking a list of maps into a set of patchwork plots and optionally save plots to file. The function is similar to papersize::make_contact_sheets().

Usage

make_atlas(
  plots,
  dims = NULL,
  ncol = NULL,
  nrow = NULL,
  page = "letter",
  orientation = "portrait",
  save = FALSE,
  filename = NULL,
  ...
)

Arguments

plots

A list of ggplot2 maps to assemble into a set of sheet maps in an atlas format.

dims

Optional. Plot dimensions. Ignored if ncol and nrow are supplied. Otherwise, if NULL (default), dims are inferred based on the dimensions of the first plot in plots.

ncol, nrow

The dimensions of the grid to create. If both are NULL, dims will be used or dims will be determined based on the plot dimensions.

page

Used by get_page_dims(), page is either a character vector passed to the name parameter of get_page_size(), a data.frame with column names matching the cols parameter, or a length 2 numeric vector with the page width and height.

orientation

Page orientation, Default: NULL. Supported options are "portrait", "landscape", or "square".

save

If TRUE, save atlas plots to files using papersize::map_ggsave_ext() Default: FALSE

filename

File name to create on disk.

...

Arguments passed on to papersize::map_ggsave_ext

name: Plot name, used to create filename (if filename is NULL) using filenamr::make_filename()
label: Label to combine with name converted to snake case with janitor::make_clean_names(). The label is designed to identify the area or other shared characteristics across multiple data files, maps, or plots. label is ignored if name is NULL or if name includes a file extension.
prefix: File name prefix. "date" adds a date prefix, "time" adds a date/time prefix; defaults to NULL.
postfix: File name postfix; defaults to NULL.
increment: If TRUE, increment digits in string by 1. If numeric, increment digits in string by value. If NULL, 0, or if no digits are present in string, return string as is.
device: Device to use. Can either be a device function (e.g. png), or one of "eps", "ps", "tex" (pictex), "pdf", "jpeg", "tiff", "png", "bmp", "svg" or "wmf" (windows only). If NULL (default), the device is guessed based on the filename extension.
fileext: File type or extension. Optional if filename or path include a file extension.
filetype: File type (used if fileext is NULL).
path: Path of the directory to save plot to: path and filename are combined to create the fully qualified file name. Defaults to the working directory.
paper: Paper matching name from paper_sizes (e.g. "letter"). Not case sensitive.
width,height: Plot size in units expressed by the units argument. If not supplied, uses the size of the current graphics device.
asp: Numeric aspect ratio used to determine width or height if only one of the two arguments is provided; defaults to NULL.
units: One of the following units in which the width and height arguments are expressed: "in", "cm", "mm" or "px".
scale: Multiplicative scaling factor.
dpi: Plot resolution. Also accepts a string input: "retina" (320), "print" (300), or "screen" (72). Only applies when converting pixel units, as is typical for raster output types.
bgcolor: Background color to optionally override plot.background theme element.
exif: If TRUE, the EXIF metadata for the exported file is updated with the exifr package; defaults to FALSE.
title: Title to add to file metadata with exiftoolr, Default: NULL.
author: Author to add to file metadata to the "Author" and "XMP-dc:creator" tags. Default: NULL.
keywords: Keyword(s) added to file metadata to "IPTC:Keywords" and "XMP-dc:Subject" tags. Defaults to NULL.
args: Alternate arguments passed to exiftoolr::exif_call(). Other tag parameters are appended to args if they are not NULL.
overwrite: If TRUE (default), overwrite any existing file with the same name or ask to overwrite if ask = TRUE. Passed to filenamr::check_file_overwrite().
ask: If TRUE, ask before overwriting file with the same name. Defaults to FALSE. Passed to filenamr::check_file_overwrite().
preview: If TRUE, open saved file in default system application. Based on ggpreview from tjmisc package.
limitsize: When TRUE (the default), ggsave() will not save images larger than 50x50 inches, to prevent the common error of specifying dimensions in pixels.
quiet: If TRUE (default), suppress function messages.
image: Image name passed to name parameter of get_social_size().
platform: Social media platform, "Instagram", "Facebook", or "Twitter", Default: NULL
format: Image format, "post", "story", or "cover", Default: NULL
single_file,onefile: If TRUE, use gridExtra::arrangeGrob() to create an arrangelist class object that ggplot2::ggsave() can save as a single multi-page file. Note: this does not work with plots modified with patchwork including inset maps created with the maplayer::layer_inset() function.

Value

OUTPUT_DESCRIPTION

Details

DETAILS

Examples

nc <- sf::read_sf(system.file("shape/nc.shp", package = "sf"))

plots <- lapply(
  dplyr::nest_by(nc, .by = NAME)[["data"]][1:4],
  function(x) {
    make_location_map(
      basemap = ggplot(),
      layer = layer_location(
        data = x,
        fill = "yellow",
        alpha = 0.5
      ),
      bg_layer = layer_location_data(
        data = nc,
        location = x,
        asp = 8.5 / 5.5,
        crop = FALSE
      ),
      neatline = layer_neatline(data = x, asp = 8.5 / 5.5),
      addon = labs_ext(caption = x$NAME)
    )
  }
)

make_atlas(
  plots = plots,
  page = "letter",
  nrow = 2,
  ncol = 1,
  save = FALSE
)
#> ℹ Creating sheet map plots
#> ✔ Creating sheet map plots [17ms]
#>
#> $`1`

#>
#> $`2`

#>
